Details

Full Cover Grill Design

Protects the woofer and tweeter in open installations.

Horn Ring Sound Enhancer

Improves mid - higher frequency sound character and reproduces life-like sound.

φ110mm Large Magnet

Produces deep bass sound with higher clarity and response.

PP + Mica Cone

Lightweight PP + Mica Cone Material provides highly responsive, clear and undistorted sound.

CS-DR693HP

Woofer

Size: 15 x 23 cm (6'' x 9'')

Diaphragm: PP

Surround: Rubber

Magnet: Ferrite

Midrange

Size: 6.6 cm (2-5/8'')

Diaphragm: Cone

Magnet: Ferrite

Super Tweeter 1

Size: 1.5 cm (19/32'')

Diaphragm: Dome

General

Power Handling Capacity (Peak Power): 600W

Power Handling Capacity (RMS): 100W

Impedance: 4 ohms

Sound Pressure Level: 85dB

Frequency Response: 50 - 18,000Hz

Weight

Weight (w.Grille): 1.5kg (3.3lbs)

Weight (w/o Grille): 1.4kg (3.0lbs)

Magnet Mass: 510g (18.0oz)

Mounting Depth: 79 mm (3-1/8")
