JVC KS-DR3004 4-channel Power Amplifier

Check for Availability with us

SKU

JVC KS-DR3004

$229.00

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Toroidal Transformer

Stable power supply is assured thanks to a large-size toroidal transformer. Its high winding density and low flux leakage improves conversion efficiency of the power. The result is natural and powerful music playback throughout the volume range.

Speaker-level Inputs for Easy Installation

DR Series amplifiers feature speaker level inputs with Auto Turn-on function. Installation is possible without having to detach the head unit.

KS-DR3004

Maximum Power Output	800W
RMS Power Output (4 ohm) [ 1% THD 14.4V]	60W x 4 (20 - 20,000Hz)
RMS Power Output (2 ohm) [ 1% THD 14.4V]	90W x 4 (20 - 20,000Hz)
RMS Power Output (Bridged 4 ohm) [ 1% THD 14.4V]	180W x 2 (1,000Hz)
Class	Class-AB
Frequency Response (+0, -3dB)	5 - 50,000Hz
Total Hamonic Distortion	< 0.04%
Signal-to-Noise Ratio (reference: 1W into 4 ohms), CEA-2006 Compliant	> 80dB
HPF	120Hz (12dB)
LPF	80Hz (12dB)
RCA Input	AL/AR, BL/BR
High Level Input (Speaker Level Input)	Yes
High Level Input Auto Power Control (Signal Sensing Turn On)	Yes
Input Sensitivity	0.2 - 15V
Protection Circuitry (Thermal / Short Circuit / Overload / DC Offset)	Yes
Anti-Pop Circuit	Yes
Dimensions (W x H x D)	322 x 52 x 185
